BEP DC Panel – 8-Way – Horizontal

58809
BEP Marine

$370.69 $210.62

0 in stock
Qty :

Description

DC Panel – 8-Way – Horizontal

BEP Marine uses the highest quality materials in its range of Control
Panels, from the marine grade aluminium base plates to the Airpax magnetic
hydraulic circuit breakers.

Features

  • Marine Grade powder coated aluminium
  • Airpax circuit breaker
  • Stylish Contour Design fascia
  • Green LED backlit labels
  • Red LED indicates systems on
  • Panels meet ABYC standards

Specifications

Total Positions: 8 Loads
Circuit Breakers: 2X 5A, 2X 10A, 3X 15A, 1X 20A
Nominal Voltage: 12V
Maximum Amperage: 160A
Dimensions: 4.5″ X 9.75″ X 2.5″
Neg Bus: 6 Way

WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Owner Manual

Waterproof Rating = NONE | Voltage = 12v | AC/DC = DC | Max Breaker Quantity = 8 | Waterproof = NONE

Additional information

Weight 2.4 lbs
Dimensions 11 × 7 × 4 in
Model Number 901H
UPC 870216002279
