Blue Sea 7042 187-Series Circuit Breaker – Panel Mount 80A

20527
Blue Sea Systems

$103.68 $62.07

12 in stock
Qty :
,

Description

7042 187-Series Circuit Breaker – Panel Mount 80A

Features:

  • Combines switching and circuit protection into a single device*
  • Precise, single-lever operation
  • “Trip Free” design cannot be held “ON” during fault current condition
  • Waterproof
  • Recessed mounting holes for clean appearance
  • Ample Clearance around terminal studs accepts heavy gauge wire lugs
  • Robust 5/16 M8 terminals provide high torque connections
  • Large lever with vertical/horizontal orientation provides indication of trip status
  • Ignition-protected – Safe for installation aboard gasoline powered boats

Specifications:

  • Amperage: 80A
  • Maximum Voltage: 48V DC
  • Mounting: Panel Mount
  • Circuit Breaker Type: Thermally responsive Bi-metal blade
  • Terminal Stud Torque: 75 in-lb (8.47 Nm)
  • Interrupt Capacity: 5000A @ 14VDC, 3000A @ 28VDC, 1500A @ 48VDC
  • Minimum Operating Temperature: -40° C
  • Maximum Operating Temperature: 85° C
  • Case Material: Thermoset Polyester
  • Circuit Breaker Class: Type III – switchable/manual reset – trip-free
  • Mounting Hole: Accept #10 (M5) Screw
  • Terminal Stud Size: 5/16″ – 18
  • Weight: 0.5lb (0.23 kg)
  • Weight: 0.50lb (0.23 kg)

* Do not use as a switch where high inrush currents are expected.

WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Amperage = 80a

Additional information

Weight 0.5 lbs
Dimensions 8 × 5 × 2 in
Model Number 7042
UPC 632085170424
