Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker

40597
Blue Sea Systems

$135.61 $81.35

10 in stock
Qty :
,

Description

7049 200 Amp Panel Mount 187 Series Circuit Breaker

Features:

  • Combines switching and circuit protection into a single device*
  • Clear, single lever operation
  • “Trip Free” design cannot be held “ON” during fault current condition
  • Waterproof
  • Recessed mounting holes for clean appearance
  • Large Clearance around terminal studs accecpt heavy gauge wire lugs
  • Robust 5/16 M8 terminals provide high torque connections
  • Large lever with vertical/horizontal orientation provides indication of trip status
  • Ignition protected – Safe for installation aboard gasoline powered boats

Specifications:

  • Interrupt Rating – 5,000 A@12V DC, 3,000A@24V DC, 1,500A@42V DC
  • Maximum Voltage Rating – 48 Volts DC
  • Operating Temperature Range – -40xC to 85xC
  • Circuit Breaker Type – Thermally responsive bi-metal blade
  • Circuit Breaker Class – Type III – switchable/manual reset – trip free
  • Terminal Stud Size – 5/16″-18
  • Terminal Stud Torque – 75 in-lb
  • Mounting Holes – Accept #10 (M5) Screw
  • Weight Lb (Kg) – 0.50 (0.23)
  • Case Material – Thermoset Polyester

WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Amperage = 200a

Additional information

Weight 0.5 lbs
Dimensions 8 × 5 × 3 in
Model Number 7049
UPC 632085070496
