Blue Sea 7310 COTS Military Grade A-Series 5 Amp

73830
Blue Sea Systems

$94.11 $62.27

0 in stock
Qty :
,

Description

7310 COTS Military Grade A-Series 5 Amp

May be suitable for use when military specifications are required under CFR 46.

Specifications:

  • Amperage: 5A
  • Actuator Style: Metal Toggle
  • Poles: 2
  • Max Voltage: 277V AC, 65V DC
  • Circuit Breaker Type: Magnetic Hydraulic – Trip Free
  • Interrupt Capacity: 1500 A AC, 7500A DC
  • Min Operating Temp: -40°C
  • Max Operating Temp: 85°C
  • Mounting Boss: 1/2-32 Hex Nut SS
  • Mounting Nut Torque: 30″-lb
  • Screw Terminal Torque: 14″-lb
  • Switching Cycles: 6000 Electrical/4000 Mechanical
  • Terminal Screw: #10-32 SS
  • Weight: 0.13lb (0.06 kg)
  • UL 1077

WarningWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Amperage = 5a

Additional information

Weight 0.45 lbs
Dimensions 4 × 3 × 2 in
Model Number 7310
UPC 632085173104
