Description
Newmar BX-1 Splash Proof Box
Model: BX-1
- Provides for secure, protected wiring connections in wheel house or below decks and engine rooms. IP rating 54 — "Splashproof"
- Rugged cast aluminum box with white enamel finish
- Metal box reduces electrical interference
- Easy wiring access through multiple grommeted cable entries
- Supplied with high quality connector strips — secure wires with compression fittings — no terminals required — see matrix below for connector strips specifications per box
Specifications
| Number of Connector Strips | 1 |
| Positions per Strip | 6 |
| Max Wire Gauge | 16 |
| Max Amps (per position) | 6 |
| Cable Entries | 2 |
| Cable Diameter | .25in |
| Box Size (inches) | 2 x 2 x 1.2 |
| Box Size (cm) | 5.1 x 5.1 x 3.1 |
What’s in the Box:
- Aluminum box
- 6-Position Connector Strip
