Description
| SI-TEX SST-10 – Specifications | |
|
Power Supply |
9.50vdc to 33.00vdc (absolute maximum) 0.045 amps nominal current draw Operation outside this range can cause erratic behavior or damage |
|
Operating Temperature |
32F?° to 122F° ( 0° to 50° C) |
|
Size |
4.3" x 4.3. x 3.5. deep (110 x 110 x 89 mm). |
|
Display Data |
Water Temperature, High and Low alarms, temperature trend arrows, alarm symbol.
|
|
Resolution |
0.01° Fahrenheit or Celsius. |
|
Accuracy |
+-00.1° F° |
|
Range |
32.00° to 99.99° F (0.00° to 37.77° C) |
|
Transducers |
Transom and bronze thru-hull temperature probes available. |
|
Display |
4 digit LCD, 5 levels of backlighting. |
|
NMEA0183 Output Sentences |
Water temperature: (Degrees C) $VWMTW,xx.xx,C*CS (Degrees F) $IIXDR,G,xx.xx*CS
|
