Uflex UP28R Rear Mount Helm 1.7 cu. 3/4″ Tapered Stainless Steel Shaft

75560
Uflex USA

$890.96 $647.43

2 in stock
Qty :

Description

UP28R Rear Mount Helm 1.7 cu. 3/4″ Tapered Stainless Steel Shaft

Features:

  • Available in four different displacement sizes
  • Compact design
  • Ball bearing piston race
  • Built-in lock valve for positive rudder lock
  • Integral relief valve for over-pressure protection
  • 3/4” tapered stainless steel shaft
  • Easily accessible lock valve and shaft seal for replacement
  • Cast iron cylinder rotor for greater durability and longer life
  • 1/4″ NPT fitting for 3/8″ tube
  • Includes 90° adjustable fittings for 3/8” tube and white bezel
  • UP45R pump is ideal for double cylinder outboard applications
  • UP45 pump is available also for inboard application
  • X68 (optional) – 40894Z Chrome bezel
  • KITF (optional) – 39664Y Remote fill adapter

Specifications:

  • Mounting: Retro-cruscotto
  • Displacement/Revolution: 28 cc-1.7 cu in
  • # of Pistons: 5
  • Relief Valve Setting: 70 Bar – 1000 PSI
  • Maximum Wheel Diameter: 710mm – 28″
  • Weight: 5kg – 11 lbs.

Cable Length (Feet) = NONE

Additional information

Weight 12 lbs
Dimensions 12 × 8 × 8 in
Model Number UP28R
UPC 702755024811
